We assure you that we always provide high quality 18 Cavities Cap Compression Machine. Help you choose the right and high-quality products to seize the market and open the market with qualified products and service, and achieve mutual benefit.
Shorter cycle time for higher productivity
Less energy consumption
High specific density
Maintenance-free molds that last decades
Quick colour changeover process
Less waste means lower costs
Model | DRCM-018 |
Production Capacity | 17000-18000/ hour (29/25MM cap) |
Cap Diameter | 20-45mm |
Cap Height | 10-30mm |
Cap Material | PP/HDPE/LDPE |
Mold Cavity No. | 18 |
Power | 380V/PH/50HZ |
Installation Power | 30KW |
Air Consumption | 0.3M3/Hr, 0.8Mpa |
Machine Dimension | 2660*1200*2000mm |
Machine Weight | 3.1T |
COMPARED WITH INJECTION MOLDING MACHINE
Item |
Cap compression molding machine |
Injection molding machine |
Number of cavity | 24 | 2*24 |
Output | 16800-23400 | 2*6000 |
Power consumption | 26 | 2*36 (with mould) |
Power consumption per month | 18720 | 51840 |
Power save per month | 33120kw | |
Cost saving | $6650 00/month (if $0 2/kw/h) | |
Using additive | No | Yes |
Using mold release | No | Yes |
Peculiar smell | No | Yes |
Product appearance | No injection point | With injection point |
Waste | No | Yes |
Manpower resource | 1 | 2 or more |
EN SHORTER CYCLE time and therefore higher productivity. The lower extrusion temperature allows the cap to be cooled in the mould more quickly: this has shortened cycle times, which have, in the case of lightweight caps, been cut to around 2 seconds.
LESS ENERGY CONSUMPTION. Lower extrusion temperatures mean less energy is needed to bring the plastic to extrusion temperature and, since the plastic is colder, less energy to cool it is needed. Overall energy savings per cap produced can be as high as 45%.
HIGH SPECIFIC DENSITY. Moulding pressure being equal, lower temperatures allow attainment of a higher specific density; moreover, the injection point, which puts added strain on the molten plastic, is absent. This technological condition provides mechanical properties and a consistency that would be unattainable with injection.
CONSISTENCY has become a major issue in beverage bottling where production lines are ever-faster and more sophisticated and where cap-related plant stoppages can no longer be tolerated.
MAINTENANCE-FREE MOULDS that last decades. The vertical and axial movement of the compression mould ensures - unlike the injection mould, burdened by its own weight – that the moulds are protected from all kinds of wear. Compression moulding means no wear on the moulds for their entire working lives.
QUICK COLOR CHANGEOVERS These can be completed quickly without having to clean a hot chamber, which is absent in the compression process. LESS WASTE lower costs.
Mould Material | Cavity | DC53, Japan |
Cavity Base | Beryllium Copper,USA | |
Cavity Pedestal | S136 .Sweden | |
Screw of Cavity Pedestal | DC53, Japan | |
Core | Beryllium Copper,USA | |
Thread Part | DC53, Japan | |
Medium Sleeve | DC53, Japan | |
De-moulding Sleeve | S136 .Sweden | |
Mould Hardness | After vacuum igniting, -180°C cryogenic treatment, nitriding, then DLC(Diamond-Like Carbon), the mould hardness is around 70 degree. |
Export standard packing
Our technician can be the buyer’s factory to install and run the machine . But the buyer should bear all the cost for the technician’s trip(include the air ticket, the cost of the accommodation and the salary)
THE DATE OF DELIEVERY: 55-60 DAYS AFTER GETTING THE DEPOSIT.
THE PORT OF DELIEVERY: NINGBO,CHINA
